Milwaukee MW306 MAX, Automatic and logging EC/TDS/NaCl/Temperature meter.
Product number: 895564
€533.50*
Please log in to receive your conditions.
Available in 7 days, delivery time 1-2 days
Product number:
895564
GTIN:
4260682386304
Measurement parameters:
EC (Electrical Conductivity), TDS (Total Dissolved Solids), NaCl (Salinity), Temperature
Measuring range:
EC Range: 0.00 to 29.99 uS/cm / 3.0 to 29.9 uS/cm | EC Range: 30.0 to 299.9 uS/cm / 300 to 2999 uS/cm | EC Range: 3.00 to 29.99 mS/cm / 30.0 to 200.0 mS/cm / up to 500.0 mS/cm, absolute conductivity* | TDS Range: 0.00 to 14.99 ppm (mg/L) | TDS Range: 15.0 to 149.9 ppm (mg/L) / 150 to 1499 ppm (mg/L) | TDS Range: 1.50 to 14.99 g/L / 15.0 to 100.0 g/l / up to 400.0 g/L absolute TDS* (with 0.80 factor) | Salinity Range: 0.0 to 400.0 %NaCl / 2.00 to 42.00 PSU | Salinity Range: 0.00 to 80.00 g/L | Temp. Range: -20.0 to 120.00°C (-4.0 to 248.0°F)
Application:
E.g. hydroponics, horticulture, laboratories, food processing, water treatment and many other applications.
Offer as PDF
Login for addressed offer The entered number of pieces will be taken into account when creating the offer.
Login for addressed offer The entered number of pieces will be taken into account when creating the offer.
Product information "Milwaukee MW306 MAX, Automatic and logging EC/TDS/NaCl/Temperature meter."
The portable 4-in-1 MW306 PRO conductivity/TDS/NaCl (salinity)/temperature meter has won many fans worldwide with its reliable fast and easy operation. It is also very rugged and has IP67 waterproof rating.
It has a user-friendly interface for data exchange and as mentioned at the beginning, it is designed to measure four different parameters of water.
Ideal for use in hydroponics, horticulture, laboratories, food processing, water treatment and many other applications with demanding measurement requirements.
Dimensions
| Height | 11,5 cm |
|---|---|
| Length | 30,5 cm |
| Width | 28 cm |
Weight
| Weight | 1,22 kg |
|---|
Other attributes
| Applications | Food, Horticulture, Laboratory, Water Treatment |
|---|---|
| Brand | Milwaukee |
| Country of origin | RO |
| Customs tariff number | 38221900 |
| Parameter | Combined Multiparameter, Conductivity and TDS, Salinity, Thermometers (°C) |
| Quality | Advanced |
Technical specifications
Electrical Conductivity
Measuring range:
0.00 to 29.99 uS/cm / 3.0 to 29.9 uS/cm
30.0 to 299.9 uS/cm / 300 to 2999 uS/cm
3.00 to 29.99 mS/cm / 30.0 to 200.0 mS/cm / up to 500.0 mS/cm, absolute conductivity*.
Resolution:
0.01 uS/cm / 0.1 uS/cm / 1 uS/cm
Sensor: MA815D/1, (4 ring)
TDS (total dissolved solids):
Measuring range:
0.00 to 14.99 ppm (mg/L)
15.0 to 149.9 ppm (mg/L) / 150 to 1499 ppm (mg/L)
1.50 to 14.99 g/L / 15.0 to 100.0 g/L / up to 400.0 g/L absolute TDS* (with factor 0.80)
Resolution:
0.01 ppm / 0.1 ppm / 1 ppm
0.01 g/L / 0.1 g/L
TDS factor: 0.40 to 0.80 / standard value: 0.50
Salinity:
Measuring range:
0.0 to 400.0 %NaCl / 2.00 to 42.00 PSU
0.00 to 80.00 g/L
Resolution: 0.1 % NaCl / 0.01 PSU / 0.01 g/L
Temperature:
Range: -20.0 to 120.00°C (-4.0 to 248.0°F)
Resolution: 0.1°C / 0.1°F
Temperature compensation: Automatic, -5.0 to 100.0°C (-23.0 to 212.0°F) or manual from -20 to 120°C (-4.0 to 248.0°F) or NO TC without temperature compensation
Conductivity temperature coefficient: 0.00 to 6.00 % / °C (EC and TDS only) | default: 1.90 % / °C
Temperature sensor: Built-in temperature sensor
Accuracy: (@ 25°C / 77°F)
EC: ±1 % of reading / ±0.05 uS/cm or 1 digit, whichever is greater
TDS: ±1 % of reading / ±0.03 ppm or 1 digit, whichever is greater
Salinity: ±1 % of reading
Temperature: ±0.5°C (±0.9°F)
Calibration
Conductivity/TDS: single cell factor calibration, 6 standards: 84 uS/cm, 1413 uS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm / one point offset: 0.00 uS/cmSalinity calibration: one point with MA9066 salinity calibration solution
Temperature calibration: no temperature calibration
Other data:
Recording: maximum 1,000 samples (max. 100 batches) / on demand, 200 samples; on stability, 200 samples / interval logging, 1000.
PC connectivity: 1 micro USB port
Battery type: 3 x 1.5 V alkaline AA (supplied)
Battery life: approx. 200 hours operating time
Auto power off: selectable 5, 10, 30, 60 min. or off
Environment: 0 to 50°C / 32 to 122°F; max. RH 95%
Dimensions: 305 x 280 x 115 mm (7.9 x 3.3 x 2.0 in.)
Housing: IP67
Weight: 1.22 kg (with battery)
Warranty: 2 years, meter
* Absolute conductivity (or TDS) is the conductivity value without temperature compensation
